GEA HILGE CONTRA

All CONTRA pumps are made of deep-drawn rolled and forged steel 1.4404/1.4435 (AISI 316L). In contrast to comparable cast materials, this achieves a very homogeneous, pore- and blowhole-free surface. These high-quality surfaces facilitate cleanability and guarantee high process reliability for a wide variety of applications in the beverage, food, dairy and pharmaceutical industries.

For pumps that are to be used in potentially explosive areas, the CONTRA is available in the Adapta variant. This design, which has an EC declaration of conformity in accordance with the ATEX guideline 2014/34/EU, can be used in categories 2 and 3.

The adaptation to customer-specific requirements is particularly noteworthy in the CONTRA pump series.
Thanks to its great variability in connections and mountings, it can be ideally adapted to customer requirements and demanding pumping tasks. Due to the extensive range of mechanical seals, an optimum sealing solution is available for every pumped medium.
The various impeller sizes and geometries make the pumps highly efficient. Additional flexibility can be achieved by operation with an integrated frequency converter. The particularly gentle pumping of even shear-sensitive media due to a very low NPSH value should be emphasized.

Thanks to an extensive variety of mechanical seals, a wide range of media and applications can be served. The single-acting, internal mechanical seals used for the CONTRA series are optimally positioned in the pump chamber.
This ensures that the mechanical seal is effectively lubricated and cooled and ensures CIP and SIP capability in accordance with the criteria for hygienic design.

The patented Adapta design enables quick and easy motor change, where the pump can remain in the pipeline. This eliminates the need for revalidation of the system in pharmaceutical applications after a motor change.

• Single mechanical seals in sterile execution
• Double mechanical seals (tandem or back-to-back)
• Standard seal face material: carbon/stainless steel and SiC/SiC
• Standard O-ring material: EPDM and FKM
• Additional designs and materials available upon request

The GEA Hilge CONTRA pump can be used flexibly for all areas of applications where reliable hygienic pump functionality is required. These include:
Beverage:

• Beer (incl. wort, mash, yeast)
• Alcoholic drinks
• Juices and concentrates
• Soft drinks
• CIP

Dairy:

• Milk
• Milk-mix drinks
• CIP

Pharma and biopharma:

• WFI (water for injection)
• Infusion
• Insulin
• Blood and blood plasma
• Nutrient solutions
• CIP

Food:

• Flavors
• Proteins
• Liquid food
• Oils
• CIP

Personal care:

• Soaps
• Cremes
• Lotions
• CIP

GEA Hilge CONTRA Adapta: Close-coupled pump with bearing bracket and coupling, horizontal installation
GEA Hilge CONTRA Adapta-SUPER: Close-coupled pump with bearing bracket and coupling, horizontal installation, motor with stainless steel shroud
GEA Hilge CONTRA Adapta-V: Close-coupled pump with bearing bracket and coupling, vertical installation
GEA Hilge CONTRA Bloc: Close-coupled pump, horizontal installation
GEA Hilge CONTRA Bloc-SUPER: Close-coupled pump, horizontal installation, motor with stainless steel shroud
GEA Hilge CONTRA Bloc-V: Close-coupled pump, vertical installation
GEA Hilge CONTRA tronic: Horizontal/vertical installation, motor with built-in frequency converter (up to 18.5 kW)
