GEA HILGE HYGIA

The GEA Hilge HYGIA also offers a high degree of flexibility.
Thanks to its great variability in connections and mountings, the HYGIA can be ideally adapted to individual customer requirements. Thanks to the extensive range of mechanical seals, an optimum sealing solution is available for every pumped medium.
The stepless alignment of the discharge port and different housing variants for up to 25 bar system pressure make the pump a flexible component in any system.
The various impeller sizes and geometries make the pumps highly efficient. Additional flexibility can be achieved by operation on an integrated frequency converter.

The CIP and SIP capable HYGIA pumps facilitate the qualification of the pump in the plant through extensive customer and requirement specific documentation and certificates like EHEDG, 3-A, FDA. Thanks to the mechanical seal optimally positioned in the pump, a flushed design can often be avoided. In addition, the pump in completely self-draining if installed vertically, even without a drain valve.

For pumps that are used in potentially explosive areas, the HYGIA is available in the Adapta variant. This design, which has an EC declaration of conformity in accordance with the ATEX guideline 2014/34/EU, can be used in device categories 2 and 3.

The quick-opening pump housing of the HYGIA series allows easy access to wearing parts. One sealing concept for the entire centrifugal pump portfolio minimizes the stocking of wear parts logistics, which is a clear advantage in terms of cost and availability for customers.
The patented Adapta design allows quick and easy motor replacement, where the pump can remain in the pipeline. Thus, revalidation of the system after an engine change is not necessary for pharmaceutical applications.

For emergencies or when fast delivery within two days is required, we have developed the GEA Hilge Fast Track program. Each pump within the program is ready to ship in 2 days, Guaranteed! Here you can find the models and information about the ordering process.

The GEA Hilge HYGIA pump can be used flexibly for all areas of application where reliable hygienic pump functionality is required. These include:
Beverage:

• Beer (incl. wort, mash, yeast)
• Alcoholic drinks
• Juices and concentrates
• Soft drinks
• CIP

Dairy:

• Milk
• Milk-mix drinks
• CIP

Pharma and biopharma:

• WFI (water for injection)
• Infusion
• Insulin
• Blood and blood plasma
• Nutrient solutions
• CIP

Food:

• Flavors
• Proteins
• Liquid food
• Oils
• CIP

• Single mechanical seals in sterile execution
• Double mechanical seals (tandem or back-to-back)
• Standard seal face material: carbon/stainless steel and SiC/SiC
• Standard O-ring material: EPDM or FKM
• Additional designs and materials available upon request

GEA Hilge HYGIA Adapta: Close-coupled pump with bearing bracket and coupling, horizontal installation
GEA Hilge HYGIA Adapta-SUPER: Close-coupled pump with bearing bracket and coupling, horizontal installation, motor with stainless steel shroud
GEA Hilge HYGIA K: Close-coupled pump with plug-in shaft connection, horizontal installation (up to 22kW)
GEA Hilge HYGIA K-SUPER: Close-coupled pump with plug-in shaft connection, motor with stainless steel shroud, horizontal installation
GEA Hilge HYGIA tronic: Motor with built-in frequency converter (up to 22 kW)
