GEA HILGE MAXA
High Quality Throughout
The GEA Hilge MAXA range is made from deep-drawn, rolled stainless steel in AISI 316L (1.4404). Flexible mounting options are available, such as a close-coupled pump, a close-coupled pump with bearing bracket or a base plate pump version (with motors up to 160 kW). The GEA Hilge MAXA range employs closed impellers with optimized efficiency and NPSH. Flange or thread connections according to ANSI or DIN standards are available.
For some GEA Hilge MAXA pump sizes, an inducer for NPSH improvements is available as an option, also a channel impeller for pumping media with high solids content.
Shaft Seals – Choose the One to Suit You
A wide range of shaft seal options is available to suit different media and applications. The mechanical seals used in the GEA Hilge MAXA range conform to DIN 24960. The single inboard seals maintain the optimum position in the liquid. This ensures efficient cleaning, lubrication and cooling.
Certificates and Documents
- Work certificates, e.g. acc. to DIN EN 10204, 2.2 or 3.1
- FDA and EHEDG certificates
- Surface roughness measurement
Seal Options
- Double mechanical seals in tandem design
- Double mechanical seals in back-to-back design
- Cartridge sealing systems (upon request)
