GEA HILGE NOVATWIN & GEA HILGE NOVATWIN+

GEA HILGE NOVATWIN & GEA HILGE NOVATWIN+

150 000 UAH

Order



GEA Hilge NOVATWIN+ is the new flexible twin screw pump series in the GEA VARIPUMP line.

The best pump for your application

The GEA Hilge NOVATWIN range allows production and cleaning with only one pump by variable speeds up to 3000 rpm. Its self-priming capability of up to 8 meters opens new application fields.

The 3-A certified pump design ensures gentle product handling with almost no pulsation, which makes the pump especially suitable for large and delicate particles.

The system pressure of 30 bar enables also high-pressure applications.

Variable combinations

The pump housing can be equipped with various hardened screw combinations. Reverse flow direction as well as flexible port positions are possible on individual customer demand. This allows the NOVATWIN range to adapt to different applications, media and operating conditions.

Shaft Seals

To accommodate different applications and media, GEA Hilge NOVATWIN are available with single or double mechanical seals.

The mechanical seals are inboard seals placed in the optimum position in the pump to ensure outstanding lubrication and cooling. They also comply with the hygienic design criteria in CIP and SIP processes.

Seal face materials are carefully selected to suit the specific media. Standard materials are silicon carbide /silicon carbide with EPDM elastomers (FDA-compliant).

Connections

  • Sterile flanges to DIN 11864-2 / DIN 11853-2
  • Threads to DIN 11851
  • Clamps to DIN 32676
  • Sterile threads to DIN 11864-1 / DIN 11853-1
  • Other connections available upon request. This includes SMS, RJT, IDF, etc., and special sterile threads and flanges

Variants

  • With bare shafts
  • With geared or standard motor and coupling mounted on stainless steel base frame
  • With stainless steel motor shroud
  • Mounted on trolley
Thermal Jackets

This option allows to either heat or cool the pump chamber depending on the temperature requirements for the pumped media.

Hardened pump housing

For abrasive media screws and additionally the pump housing can be hardened to ensure a longer lifetime of the pump.

The GEA Hilge NOVATWIN pumps are suitable for a variety of applications, such as:

Dairy

  • Сream Cheese
  • Butter
  • Yoghurt
  • Sour Cream
  • Ice Cream

Food

  • Sugar solution
  • Chocolate
  • Sauces
  • Soups
  • Mayonnaise
  • Pastes
  • Oils & Fats
  • Prepared Salads
  • Pet Food

Beverage

  • Smoothies
  • Juice Concentrate
  • Pre-mixes
  • Brewing Yeast

Pharma & Biopharma

  • Neutraceuticals
  • Blood Products
  • Vaccines
  • Enzymes
  • Cell cultures

Personal Care & Home Care

  • Cosmetics
  • Body & Skincare
  • Fabric care
  • Household Cleaners
