GEA HILGE TPS

The GEA Hilge TPS series has been designed for a variety of applications within:

• Beer
• Wort
• Yeast
• Water
• CIP Solutions
• Milk
• Cream
• Yoghurt
• Whey
• Brine
• CIP Solutions
• Oils
• Sauces
• Stock
• Brine
• Flavors
• Ice-cream mix
• CIP Solutions

• CIP solutions
• Tank emptying
• Gas conveying

• Operating pressure max. 16 bar
• Low NPSH value avoids early cavitation to the pump
• Energy-efficient operation thanks to optimized speed control and/or impeller trimming

• Open impeller design optimized for gentle product handling
• Wetted components made of 1.4404 or 1.4409 (AISI 316L)
• Surface roughnesses of Ra = 0.8 µm can be achieved by mechanical treatment of the surface (higher surface qualities on request)
• High-efficiency IE3 motors

• Gentle product handling
• Standard connection: DIN 11853-2 Hygienic groove flange
• Low wear part stock requirement thanks to modular concept
• Acceptance test certification 3.1 (optional)
• EHEDG certified
• Sealings comply to FDA and USP Class IV

• Mechanical seal unit can be removed from the front
• Flushing unit easy to retrofit
• Pump shaft protected by wear sleeve
• Only two mechanical seal sizes for the entire pump series
• Seal face material options: carbon/silicon carbide (standard), silicon carbide/silicon carbide
• Various elastomers with FDA approval (EPDM, FKM)

The elastomer sealing is executed according to EHEDG standards. The special groove enables the seal is kept reliably in place at all times. The shape of the groove is based on FEM analyses. The metallic stop allows a defined compression of the seal, ensuring gap-free sealing against the product chamber without dead corners.
